LP6

Board washing machine
Modular board washing machine with adjustable rotary brushes for simultaneously cleaning all four sides of boards in different sizes.
  • Four-sided cleaning thanks to rotary brushes that clean all surfaces simultaneously.
  • Adaptability to different board sizes with adjustable brush spacing.
  • Modular design allowing the machine to be configured according to washing requirements.
  • Efficient water circuit with an 800-litre tank and a closed-loop pump delivering up to 160 L/min.
  • Easy maintenance thanks to a streamlined, accessible design.

The LP6 is a board washing machine designed to ensure efficient and consistent cleaning of boards used in cheese maturation cellars. Its modular design allows it to be adapted to different washing requirements and installation configurations.

Its cylindrical rotary brushes clean all four sides of the board simultaneously, ensuring thorough cleaning in a single pass. The distance between the brushes is adjustable, allowing the machine to handle different board types and sizes.

The LP6 features an 800-litre tank and a closed-loop water system with a pump flow rate of up to 160 L/min. The water temperature can be adjusted up to 60°C to suit the cleaning requirements of the installation.

Its streamlined design facilitates cleaning and maintenance. The machine can also be configured with various options, including water heating, disinfection, high-pressure rinsing, spin-drying and infeed and outfeed conveyors.

With a throughput of approximately 180 boards per hour for boards measuring 2,300 mm, the LP6 is a suitable solution for the regular washing needs of cheese dairies and cheese maturers.

  • Type: Board washing machine with cylindrical rotary brushes
  • Cleaning: All four sides simultaneously
  • Adjustment: Adjustable brush spacing
  • Throughput: Approx. 180 boards/hour for boards measuring 2,300 mm
  • Tank capacity: 800 L
  • Weight: Approx. 1,300 kg
  • Number of operators: 2 (1)
  • Rinsing: Mains water supply
  • Controls: Touchscreen interface
  • Water heating
  • Closed-loop board disinfection
  • Spray disinfection of boards
  • Board spin-drying
  • Adaptation for short boards measuring 900 mm
  • Pre-rinsing
  • Automatic board height adjustment
  • High-pressure rinsing
  • Infeed and outfeed conveyors

For all technical information and specifications, please refer to our product datasheet.
